The principle of the aluminum ingot casting machine is to utilize the melting and solidification process of the aluminum ingot, heat the aluminum scrap to the melting temperature, and then inject the molten aluminum liquid into the casting mold through the launder, and then cool and harden to form an aluminum ingot.
The aluminum alloy ingot casting unit is used for fully automatic control and production of various grades of cast aluminum alloy ingots. The casting unit can meet the requirements of continuous production 24 hours a day, and the production process requirements of casting and automatic stacking of various grades of cast aluminum alloy ingots.
After the aluminum alloy liquid flows into the distributor of the ingot casting machine, the distributor is evenly injected into the aluminum ingot mold of the chain ingot casting machine, and the ingot mold is cooled at the bottom of the mold until the indirect water-cooled aluminum ingot is sufficiently cooled and solidified After forming, the aluminum ingots are dropped on the ingot chute through the mechanical rapping and demoulding device, and the finished ingots are stacked manually according to the prescribed procedures, and then transported to the warehouse area by the forklift in the factory.
| No. | Name | Parameter |
| 1 | Casting Speed | 0～3.9m/min (0～24 ingots/min), Generally Speed：2m/min |
| 2 | Weight of Single Aluminum Ingot | 6.5kg |
| 3 | Cooling Method | Water Cooling |
| 4 | Temperature (When The Ingot Demoulded) | 120~270℃ |
| 5 | Weight of Single Ingot Mold | 22-24kg |
| 6 | Casting Method | Automatic Liquid Separation and Continuous Casting |
| 7 | Production Line Length | 16 Meters |
| 8 | Aluminum Ingot Mold Quantity | 190 Pieces |
Ingot Weight: 6.5Kg , 15Kg , etc
Capacity: from 10 meters to 22 meters
Can Be Customized
