The roller type enamel pot enamel drying and firing furnace is a continuous production line, suitable for large-scale, multi-variety, multi-specification drying and high-temperature sintering of various enamel pots such as cast iron pans, steak pots, round stew pots, etc. Except for the manual operation of the workpiece on and off the line and the swing, the rest of the transportation, drying and firing are automatically completed on this equipment.
The inner liner is coated with enamel machine (prepared by the user) for uniform glazing → transferred to the drying chain → fully dried in the oven → inspected and cleaned after exiting the drying box, transferred to the firing chain → heat exchange between cold and hot products, preheating → high temperature firing → heat exchange between hot and cold products, cooling → sintering completed
1). After high-temperature firing, the hot products on the discharge line exchange heat with the cold products to be fired on the feed line, which greatly improves the thermal efficiency of the enamel furnace.
2). The furnace adopts a high-temperature-resistant pre-compressed aluminum silicate fiber structure, which makes it easy to stop and start the furnace. It replaces the old refractory brick kiln structure and solves the impact of rapid cooling and heating on the equipment.
3). Use resistance band radiation heating to replace the coal-fired structure. The equipment has no emissions and pollution, and fully meets the requirements of environmental protection.
4). You can choose to start the furnace during low-peak electricity price periods, which can significantly reduce power consumption and directly reduce electricity bills.
5). Suitable for high-temperature firing of various types and specifications of workpieces in the inner tank.
6). Suitable for dry and wet enameling process conditions of products.
7). The temperature control instrument digitally displays the set temperature and the actual temperature in the furnace, and automatically performs PID temperature control. It is very simple to operate and use, and at the same time greatly improves the energy saving effect.
8). The upper and lower line operating positions are ample, the height is moderate, and the temperature is low, which improves working conditions.
9). Easy maintenance and low repair cost.
10).The whole is a detachable assembly structure, which is convenient for transportation and movement.
This electric furnace is suitable for sintering enamel liner, enamel water tank, and solar water heater tank.
Our company can provide a complete set of production processes
