Electric arc furnace is an electric furnace that uses the high temperature generated by the electrode arc to melt ores and metals. When the gas discharge forms an arc, the energy is very concentrated, and the temperature in the arc zone is above 3000℃. For melting metal, the electric arc furnace has greater process flexibility than other steelmaking furnaces, can effectively remove impurities such as sulfur and phosphorus, and the furnace temperature is easy to control, which is suitable for the melting of high-quality alloy steel.
| Model | Inner Diameter | Transformer Capacity | Electrode Diameter | Cooling Water Consumption |
| DM-EAF0.5 | 1600mm | 650KVA | 150mm | 30T |
| DM-EAF1.5 | 2500mm | 1250KVA | 200mm | 45T |
| DM-EAF3 | 3000mm | 2200KVA | 250mm | 50T |
| DM-EAF5 | 3400mm | 3200KVA | 300mm | 80T |
| DM-EAF10 | 3500mm | 6300KVA | 350mm | 130T |
| DM-EAF15 | 3800mm | 8000KVA | 350mm | 180T |
| DM-EAF20 | 4200mm | 10000KVA | 400mm | 240T |
| Can Be Customized | ||||
