Feature (1700 Type):
Be customized to keep the operator
away from the heat source
auto control
Standard Parts: Fire Brick(Below 300*300*300mm),Operation Manual
Optional Parts: 7 inch touch screen; Gas Vent; Observation Hole; Furnace Furniture; Alumina crucible; Software
Technical Parameter (1700 Type):
| Model | Max Temperature
(°C) |
Inner Size
(W *H * D) mm |
Volume
(L) |
Power
(KW) |
Phase | Thermocouple |
| DM-17M-1 | 1700 | 100*100*100 | 1 | 1 | 1 | B type |
| DM-17M-2 | 1700 | 120*120*130 | 2 | 3 | 1 | B type |
| DM-17M-3 | 1700 | 150*150*150 | 3 | 4 | 1 | B type |
| DM-17M-5 | 1700 | 150*150*200 | 5 | 5 | 1 | B type |
| DM-17M-8 | 1700 | 200*200*200 | 8 | 7 | 1 | B type |
| DM-17M-12 | 1700 | 200*200*300 | 12 | 8 | 1 | B type |
| DM-17M-27 | 1700 | 300*300*300 | 27 | 10 | 3 | B type |
| DM-17M-36 | 1700 | 300*300*400 | 36 | 12 | 3 | B type |
| DM-17M-64 | 1700 | 400*400*400 | 64 | 20 | 3 | B type |
| DM-17M-125 | 1700 | 500*500*500 | 125 | 30 | 3 | B type |
| DM-17M-216 | 1700 | 600*600*600 | 216 | 45 | 3 | B type |
| DM-17M-512 | 1700 | 800*800*800 | 512 | 80 | 3 | B type |
| DM-17M-729 | 1700 | 900*900*900 | 729 | 96 | 3 | B type |
| DM-17M-1000 | 1700 | 1000*1000*1000 | 1000 | 120 | 3 | B type |
| Can Be Customized | ||||||
