Feature (1400 Type):
customized to keep the operator away from the
heat source
Standard Parts:
Fire BrickFire Brick(Below 300*300*300mm),
Operation Manual
Optional Parts: 7 inch touch screen; Gas Vent; Observation Hole; Furnace Furniture; Alumina crucible; Software
Technical Parameter (1400 Type):
| Model | Max temperature(°C) | Inner Size
(W *H * D) mm |
Volume
(L) |
Power
(KW) |
Phase | Thermocouple |
| DM-14S-1 | 1400 | 100*100*100 | 1 | 1 | 1 | S type |
| DM-14S-2 | 1400 | 120*120*130 | 2 | 2 | 1 | S type |
| DM-14S-3 | 1400 | 150*150*150 | 3 | 3 | 1 | S type |
| DM-14S-5 | 1400 | 150*150*200 | 5 | 4 | 1 | S type |
| DM-14S-8 | 1400 | 200*200*200 | 8 | 5 | 1 | S type |
| DM-14S-12 | 1400 | 200*200*300 | 12 | 7 | 1 | S type |
| DM-14S-27 | 1400 | 300*300*300 | 27 | 9 | 1 | S type |
| DM-14S-36 | 1400 | 300*300*400 | 36 | 11 | 3 | S type |
| DM-14S-64 | 1400 | 400*400*400 | 64 | 18 | 3 | S type |
| DM-14S-125 | 1400 | 500*500*500 | 125 | 27 | 3 | S type |
| DM-14S-216 | 1400 | 600*600*600 | 216 | 40 | 3 | S type |
| DM-14S-512 | 1400 | 800*800*800 | 512 | 70 | 3 | S type |
| DM-14S-729 | 1400 | 900*900*900 | 729 | 88 | 3 | S type |
| DM-14S-1000 | 1400 | 1000*1000*1000 | 1000 | 110 | 3 | S type |
| Can Be Customized | ||||||
